Bottom Brackets

Why We Make It We build bearings, so we build bottom brackets. The humble threaded bottom bracket is often the first part installed on a new frame, and the last one the rider thinks about during the life of the bike, but the bottom bracket has a direct effect on pedaling efficiency (read: speed). This is where you put your power into the bike. Having the absolute best interface between your effort and your bike’s forward momentum makes your ride better. The Threadfit™ 24 is how we make bikes that take 24mm cranks the best they can be. Why You Want It ThreadFit™ 24 fits 24mm cranks in BSA bottom bracket shells. Our ThreadFit™ 24 bottom bracket is designed and built to be durable, serviceable, and silent. Manufactured to create the most precise interface between your frame’s bottom bracket shell and your cranks, it makes your cranks spin lightly and easily, without interference, for the lifetime of your bike (with a little regular service). King’s legendary, angular-contact bearings, both steel and ceramic, are the best in the industry, and actually get faster over time, as their contact surfaces wear. You want this bottom bracket because it offers super low drag. You want this bottom bracket, because it can be opened, cleaned and repacked for years of faithful service. You want this bottom bracket, because you don’t want to think an awful lot about your bottom bracket. Our Threadfit™ 24 bottom brackets come in an array of beautifully anodized colors and each one includes a Fit Kits that allow our ThreadFit™ 24 to be used with a wide selection of road and mountain bike cranks. - Engineered, manufactured and assembled in Portland, Oregon USA - King Lifetime Warranty - Legendary made-in-house bearings - Available in 8 beautifully anodized colors - A Fit Kit is required for use and included in the purchase prices - Ceramic bearing upgrade available

PF30 Threaded bottom bracket features two machined aluminum cups that thread together ensuring the bottom bracket remains stable in the frame, increasing bearing life, and simplifying maintenance. This means no more creaking, smoother operation, longer bearing life, and really quick bearing replacement. Directly replaces all OEM PF30 bottom brackets. Note: Use only bottom bracket tools compatible with 16-notch, 48.5mm outer diameter cups. - Bearings: Enduro Angular Contact - Color: Black - Bottom Bracket/Frame Interface: PF30, Specialized Carbon OSBB, BBRight™ Press Fit - Bottom Bracket Shell Width (mm): 61mm to 79mm - Bottom Bracket Shell I.D.: 46mm - Crank Spindle Type: BB30 - Crank Spindle Diameter: 30mm - Weight: 114g

Threaded ABEC-3 BB for 386EVO frames (86.5mm shell width, 46mm shell ID). Machined cups thread together for stability, increased bearing life, and simple installation and maintenance. No more creaking. Smooth operation. Fast bearing replacement. - Bearings: Enduro ABEC-3 - Color: Black - Bottom Bracket/Frame Interface: BB386EVO - Bottom Bracket Shell Width (mm): 86.5mm - Bottom Bracket Shell I.D.: 46mm - Crank Spindle Type: BB30 - Crank Spindle Diameter: 30mm - Weight: 126g - Packaged for retail display - Will accept 24mm and 24/22mm cranksets using Wheels Mfg. 386EVO BB / Crank Adapters

Wheels Mfg BB86/92 thread together bottom bracket for use with 24mm spindle diameter cranksets. The two machined aluminum cups thread together ensuring the bottom bracket remains stable in the frame, increasing bearing life, and simplifying maintenance. This means no more creaking, smoother operation, longer bearing life, and really quick bearing replacement. Note: Use only bottom bracket tools compatible with 16-notch, 48.5mm outer diameter cups. - Bearings: Enduro ABEC-3 - Color: Black - Bottom Bracket/Frame Interface: BB86, BB92 - Bottom Bracket Shell Width (mm): 86mm, 92mm, 89.5mm - Bottom Bracket Shell I.D.: 41mm - Crank Spindle Type: Shimano Hollowtech II, FSA MegaExo, RaceFace EXI - Crank Spindle Diameter: 24mm - Weight: 106g

BBRight™ Outboard bottom bracket for use with 24mm spindle diameter cranksets. The two machined aluminum cups thread together ensuring the bottom bracket remains stable in the frame, increasing bearing life, and simplifying maintenance. This means no more creaking, smoother operation, longer bearing life, and really quick bearing replacement. - Bearings: Enduro ABEC-3 - Color: Black - Bottom Bracket/Frame Interface: BBRight™ Press Fit - Bottom Bracket Shell Width (mm): 79mm - Bottom Bracket Shell I.D.: 46mm - Crank Spindle Type: Shimano Hollowtech II, FSA MegaExo, RaceFace EXI - Crank Spindle Diameter: 24mm - Weight: 148g

External English (BSA) threaded road bottom bracket for 68mm shells. Wheels Mfg uses only Enduro bearings and silicone seals for the most durable and smoothest bottom brackets available. Fully serviceable. Includes: (2) - Enduro Silicone dust seals (1) - 2.5mm aluminum BB cup spacer (2) - 0.5mm crank spindle spacers (2) - 1.0mm crank spindle spacers Direct replacement for SRAM/Truvativ GXP bottom brackets! - Bearings: Enduro Angular Contact - Color: Gray - Bottom Bracket/Frame Interface: ISO/English or BSA Threaded (1.37 in x 24 TPI) - Bottom Bracket Shell Width (mm): 68mm - Bottom Bracket Shell I.D.: 33.6-33.9 mm - Crank Spindle Type: GXP (SRAM, Truvativ, Etc.) - Crank Spindle Diameter: 22/24mm - Weight: 111g

External English (BSA) threaded bottom bracket for 73mm shells. Wheels Mfg uses only Enduro bearings and silicone seals for the most durable and smoothest bottom brackets available. Fully serviceable. Includes: (2) - Enduro Silicone dust seals (1) - 2.5mm aluminum BB cup spacers for use with 68mm wide BB shell (1) - 1.8mm aluminum BB cup spacers for use with 68mm wide BB shell (1) - 0.7mm aluminum BB cup spacers for use with 68mm wide BB shell (2) - 0.5mm crank spindle spacers (2) - 1.0mm crank spindle spacers (1) - Wave Washer Direct replacement for SRAM/Truvativ GXP bottom brackets! - Bearings: Enduro ABEC-3 - Color: Red - Bottom Bracket/Frame Interface: ISO/English or BSA Threaded (1.37 in x 24 TPI) - Bottom Bracket Shell Width (mm): 68-73mm - Bottom Bracket Shell I.D.: 33.6-33.9 mm - Crank Spindle Type: GXP (SRAM, Truvativ, Etc.) - Crank Spindle Diameter: 22/24mm - Weight: 116g

The Wheels Mfg original PF30 bottom bracket is a significant upgrade to any OEM PF30 bottom bracket. Two machined aluminum cups offer increased durability and bearing life, while keeping a simple press together method for installation and maintenance. This means no more creaking, smoother operation, longer bearing life, and really quick bearing replacement. - Bearings: Enduro Angular Contact - Color: Black - Bottom Bracket/Frame Interface: PF30, BB386EVO, Specialized Carbon OSBB, BBRight" Press Fit - Bottom Bracket Shell Width (mm): 61mm to 86.5mm - Bottom Bracket Shell I.D.: 46mm - Crank Spindle Type: BB30 - Crank Spindle Diameter: 30mm - Weight: 112g

- Left and right bottom bracket cups with standard bearings for FSA MegaExo cranks - BB-9050 is for 24mm spindle 68/73mm MTB K-Force and Team Issue cranks - BB-8681 for K-Force Light (a non-ceramic option) and SLK Light Road MegaExo cranks (BB-8681 bearing covers have been redesigned so that the spindle now rides directly on the bearing itself) - BB-7000 is for 24mm spindle 68/73mm shell MTB Gravity Lite, Moto X and Afterburner cranks - BB-7000 is for 24mm spindle 83mm shell MTB Gravity Lite cranks - BB-6200 is for 24mm spindle 68mm shell Energy, Gossamer and Omega No Bolt Design cranks - BB-6000 is for 24mm spindle 68mm shell Energy, Gossamer and Omega cranks - BB-4000 is for 19mm spindle 69mm shell Omega cranks - BB-1000 is for 19mm spindle 68/73mm MTB Gamma cranks - 1.37" x 24tpi (English threads) or M36 x 24tpi (Italian threads)

SRAM saw the opportunity to make a better press fit system where all the best from BB30 and PressFit bottom brackets would be combined into one captivating package. Pressfit 30 will feature an integrated seal, pre-assembled into the cups, to further prolong bearing life. The key difference with Pressfit 30 is how the bearings are fitted into the frame. Bearings are housed in nylon cups which will be pressed into the frames bottom bracket shell. This bottom bracket is designed for 30mm spindle cranksets. Frames will need a 46mm inner-diameter bottom bracket shell to accommodate this system. Pressfit 30 for road will require a 68mm wide shell while Pressfit 30 for MTB will require a 73mm wide shell. - Easy installation - PressFit cups for lighter weight - Narrow Q-factor and more ankle clearance - Integrated gutter seal to prolong life - Integrated adjuster - 30mm spindle diameter

Genuine replacement parts Praxis bottom brackets feature precise tolerances and quality materials to ensure smooth, quiet spinning for many miles. No more creaking. Smooth operation. Fast bearing replacement. - For use with Trek T47 frames with 85.5mm bottom bracket shells - Compatible with Shimano 24mm cranks

SRAM's GXP Team PressFit MTB Bottom Bracket Cups are the premium choice for getting the most out of every pedal stroke. They feature smooth bearings that keep drag to a minimum and seals that keep debris out. Plus, these BB cups press directly into the frame without having to be threaded in for reduced weight and enhanced durability.

Get more distance out of every pedal stroke with SRAM's BB30 Bottom Bracket Assembly. It features sealed bearings for a smooth pedal stroke and impressive reliability. Plus, it presses directly into your frame's BB30 bottom bracket shell for reduced weight and increased longevity.

Pressfit Model: • For use on BB86/92 bottom bracket shells • Compatible with 24mm spindle Hollowtech II cranksets • BB Shell Width (mm): 92 mm • BB/Frame Interface: BB86 , BB92 • Bottom Bracket Shell I.D.: 41 • Defined Color: Black • Spindle Interface Type: Shimano Hollowtech II Threaded Model: • Includes 3 x 2.5mm spacers • Includes TL-FC24 adapter tool • Reduced size for light weight • New seal construction for smoother rotation • Requires TL-FC34 or included TL-FC24 adaptor for installation & removal • BB Shell Width (mm): 68 mm • BB/Frame Interface: English • Defined Color: Black • Spindle Interface Type: Shimano Hollowtech II • Weight: 77 g

Shimano Dura-Ace BB92, BB9000 Hollowtech II Bottom Brackets

Genuine replacement parts Revive your ride with a fresh set of bearings for your BB90/95 equipped carbon bike. Proprietary replacement bottom bracket for the Trek family of bikes. - Only compatible with 24mm cranks - Not compatible with BB30 cranks

Shimano's Ultegra bottom bracket uses Pro Tour-proven technology for lighter weight and super smooth spinning, while still maintaining the same level of durability and stiffness. It's available in English, Italian, or Press Fit models.

Shimano's BB-UN55 Square Spindle Bottom Brackets are the unofficial standard for English-threaded cartridge bottom brackets. Quality, value, and durability come together to keep you cranking for many, many miles. - Fits JIS Square-Taper Cranksets - Hollow spindle - Crankarm fixing bolts not included

- Tiagra-level Hollowtech II bottom bracket - Compatible with all road Hollowtech II cranks

- Simple and reliable square taper bottom bracket - Replaces both BB-UN26 and BB-UN55 - Sealed cartridge bearings - Cr-Mo axle - For bicycles equipped with a chain case, select BB-UN300-K - For E-type front derailleur compatibility, choose BB-UN300-E - Fixing bolts not included; Shimano FC-E6000 bolts suggested

- Simple and reliable square taper bottom bracket - Replaces both BB-UN26 and BB-UN55 - Sealed cartridge bearings - Cr-Mo axle - For bicycles equipped with a chain case, select BB-UN300-K - For E-type front derailleur compatibility, choose BB-UN300-E - Fixing bolts not included; Shimano FC-E6000 bolts suggested

BB-UN26 cartridge bottom bracket. - Smooth rotation - Square taper spindle - Sealed cartridge bearing assembly
